Straight Titanium Alloy Wire EN10204 ISO5832 TiGr1 TiGr2 TiGr3 For Jewelry
| Place of Origin: | China |
| Brand Name: | BaseTi |
| Certification: | ISO9001:2015 |
| Model Number: | TS013 |
| Minimum Order Quantity: | NO MOQ LIMITATION. |
| Price: | CONTACT US |
| Packaging Details: | External: wooden box packaging; Inside: an inner packing with protective foam; |
| Delivery Time: | 10~18 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 10,000 tons/month |
|
Detail Information |
|||
| Place of Origin | China | Brand Name | BaseTi |
|---|---|---|---|
| Certification | ISO9001:2015 | Model Number | TS013 |
| Material Composition: | Ti > 90%, Alloy Elements Vary | Material Grade: | ASTM: Grade 1, 2, 3, 4, Ti-6Al-4V; European: TiGr1, TiGr2, TiGr3, TiGr4, Ti6Al4V |
| Production Standards: | ASTM: B348; European: EN 10204, ISO 5832 | Application Field: | Medical, Electronics, Jewelry, Aerospace |
| Tensile Strength: | 240-950 MPa (Depending On Grade) | Diameter: | 0.1mm - 3.0mm |
| Elongation: | 8-25% (Depending On Grade) | Melting Point: | 1,668°C (3,034°F) |
| Purity: | 99.2% Or Higher | Surface Finish: | Bright, Smooth, Free Of Oxides |
| High Light: | Straight titanium alloy wire,titanium alloy wire EN10204,titanium welding wire TiGr2 TiGr3 |
||
Product Description
Straight-Length Titanium Wire EN 10204, ISO 5832 TiGr1, TiGr2, TiGr3, TiGr4, Ti6Al4V For Medical, Electronics, Jewelry
*If you have any requirements for customized Straight-length Titanium Wire, we would be delighted to further discuss the technical specifications with you and provide a quotation.
*Our production capacity is efficient, and our logistics channels are well-developed. We can deliver products via international express to any corner of the globe within 3 to 7 days.
| Feature |
Specification / Range |
|---|---|
| Material Grade (USA) | Grade 1, 2, 3, 4, Ti-6Al-4V |
| Material Grade (Europe) | TiGr1, TiGr2, TiGr3, TiGr4, Ti6Al4V |
| Production Standards (USA) | ASTM: B348 |
| Production Standards (Europe) | EN 10204, ISO 5832 |
| Material Composition | Ti > 90%, Alloy Elements Vary |
| Application Field | Medical, Electronics, Jewelry, Aerospace |
| Diameter | 0.1mm - 3.0mm |
| Tensile Strength | 240-950 MPa (Depending on grade) |
| Elongation | 8-25% (Depending on grade) |
| Melting Point | 1,668°C (3,034°F) |
| Purity | 99.2% or higher |
| Surface Finish | Bright, Smooth, Free of Oxides |
| Conductivity | Moderate electrical, High thermal |
| Corrosion Resistance | Exceptional |
| Additional - Density | 4.51 g/cm³ |
| Additional - Modulus of Elasticity | 105 - 120 GPa |
The Art and Science of Titanium Wire: Unveiling Real-world Solutions Across Grades
When it comes to advanced material science applications, Titanium Wire effortlessly stands out, offering a remarkable blend of resilience and versatility that's tailored to meet an extensive range of industrial requirements.
Exploring the Intricacies of Different Grades and Their Applications
-
Grade 1: Known for its high ductility, this grade is ideal for applications demanding extreme formability. It is extensively used in chemical plants and other corrosive environments.
-
Grade 2: Representing the perfect balance between mechanical strength and pliability, this grade finds its applications predominantly in automotive and aerospace sectors.
-
Grade 3: With enhanced mechanical properties, Grade 3 becomes an essential material in heavy-duty industrial applications requiring added strength.
-
Grade 4: As the pinnacle of unalloyed grades, it specializes in delivering robust performance in severe environmental conditions like marine and aerospace.
-
Ti-6Al-4V (Grade 5): This sophisticated alloy is the go-to material for advanced engineering applications, taking both design and material science to the next level.
Highlighting Key Benefits of Titanium Wire
Advantages of using Titanium Wire include:
- Outstanding Corrosion Resistance: Ideal for use in various environmental conditions.
- Superior Strength-to-Weight Ratio: Maximizes performance without compromising on weight.
- Exceptional Biocompatibility: Unsurpassed in medical applications.
- Heat Resistance: Maintains mechanical properties even in high temperatures.
BaseTi: A Name Synonymous with Titanium Excellence
BaseTi has positioned itself as a leading titanium manufacturer and titanium supplier. It epitomizes precision and quality, making it a natural choice for those seeking the best in titanium solutions.
Closing Thoughts
With its plethora of grades and diverse applicability, Titanium Wire is set to revolutionize industries, offering practical solutions that blend innovation with efficacy.
| Grade | U.S. Standards (ASTM) | European Standards (EN) | Application Fields |
Specific Products |
|---|---|---|---|---|
| Grade 1 | ASTM B863 | EN 10204-3.1 | Medical, Chemical Processing | Catheters, Wire Mesh |
| Grade 2 | ASTM B863 | EN 10204-3.1 | Aerospace, Automotive | Fasteners, Springs |
| Grade 3 | ASTM B863 | EN 10204-3.1 | Structural Engineering | Frames, Supports |
| Grade 4 | ASTM B863 | EN 10204-3.1 | Marine, Aerospace | Propeller Shafts, Aircraft Frames |
| Ti-6Al-4V (Grade 5) | ASTM B863, AMS 4954 | EN 10204-3.1 | High-Performance Applications | Aerospace Components, Surgical Implants |
Note: Make sure to source your Titanium Wire from reputable titanium suppliers and manufacturers for assured quality.
This structured approach to Titanium Wire grades and their corresponding applications presents a valuable resource for both experienced professionals and those new to the field. Coupled with the top-notch quality offered by leading manufacturers, such as BaseTi, it is easier than ever to select the most appropriate Titanium Wire for specific needs.
|
Grade |
ASTM Standards |
Density (g/cm³) |
Tensile Strength (MPa) |
Elongation (%) |
Melting Point (°C) |
|---|---|---|---|---|---|
|
Grade 1 |
ASTM B863 |
4.51 |
240-370 |
24 |
1670 |
|
Grade 2 |
ASTM B863 |
4.5 |
345-450 |
20 |
1670 |
|
Grade 3 |
ASTM B863 |
4.5 |
450-620 |
18 |
1670 |
|
Grade 4 |
ASTM B863 |
4.5 |
550-790 |
15 |
1670 |
|
Ti-6Al-4V |
ASTM B863, AMS 4954 |
4.43 |
900-1000 |
14 |
1660 |
|
Grade |
ASTM Standards |
Ti (%) |
Al (%) |
V (%) |
Fe (%) |
O (%) |
|---|---|---|---|---|---|---|
|
Grade 1 |
ASTM B863 |
>99.5 |
- |
- |
0.20 |
0.18 |
|
Grade 2 |
ASTM B863 |
>99.2 |
- |
- |
0.30 |
0.25 |
|
Grade 3 |
ASTM B863 |
>99.1 |
- |
- |
0.30 |
0.35 |
|
Grade 4 |
ASTM B863 |
>99.0 |
- |
- |
0.50 |
0.40 |
|
Ti-6Al-4V |
ASTM B863, AMS 4954 |
90 |
6 |
4 |
0.25 |
0.20 |
